Calcium Silicate Coated Fiberglass High Temperautre Fabric

Weight: 640gsm~2700gsm| Thickness: 0.6~3.0mm

Coating: Calcium Silicate| Base Fabric: Fiberglass Fabric /Fiberglass Fabric with S.S. wire reinforced.

Work Temperature

Long Time: 400℃

Short Time: 650℃

Free Sample Available!
Whatsapp/Phone: +86 13207127986

Technical Specs

Applications

High Temp Resistance, Thermal Insulation

Coating

Calcium Silicate

Color

Grey(gray)

Thickness(mm)

0.6mm-0.7mm, 1.0mm-1.5mm, 1.5mm-2.0mm, 2.0mm-3.0mm

Description

Calcium silicate coated fiberglass fabric is a specialized type of fabric that is commonly used in high-temperature applications. It consists of a woven fiberglass substrate that is coated or impregnated with a layer of calcium silicate.

Here are the key features and characteristics of calcium silicate coated fiberglass fabric:

Heat Resistance: The primary purpose of the calcium silicate coating is to enhance the fabric’s heat resistance. Calcium silicate is a highly refractory material that can withstand high temperatures without significant degradation. It has a remarkable capability to withstand short-term exposures up to 650°C, providing exceptional high temperature performance. In addition, the fabric is engineered for long-term use in high temperature environments. It maintains its integrity and functionality with a work temperature of 400°C, ensuring durability and reliability.

Calcium Silicate Coated Fiberglass High Temperautre Fabric

Fire Resistance: The coating also provides the fabric with excellent fire resistance. It is non-combustible and can act as a barrier to prevent the spread of flames. This property makes calcium silicate coated fiberglass fabric suitable for applications that require fireproofing or heat insulation.

Calcium Silicate Coated Fiberglass High Temperautre Fabric

Insulation Properties: Calcium silicate has low thermal conductivity, which means it can effectively insulate against heat transfer. The fabric’s insulation properties make it useful for applications where temperature control is crucial, such as in thermal insulation jackets, fire barriers, removable insulation covers, and expansion joint seals.

Calcium Silicate Coated Fiberglass High Temperautre Fabric

Chemical Resistance: Calcium silicate coated fiberglass fabric is resistant to most chemicals, acids, and alkalis. It can withstand exposure to various industrial chemicals without significant degradation, making it suitable for applications in corrosive environments.

Calcium Silicate Coated Fiberglass High Temperautre Fabric

Flexible and Durable: The fiberglass substrate provides the fabric with flexibility and durability. It can be easily cut and fabricated into different shapes and sizes to fit specific applications. The fiberglass reinforcement also increases the fabric’s mechanical strength and tear resistance.

Thermal Stability: Calcium silicate exhibits excellent thermal stability, even under extreme temperature conditions. It does not shrink, melt, or produce toxic fumes when exposed to high heat.

Applications of calcium silicate coated fiberglass fabric include:

Insulation covers and jackets for pipes, valves, boilers, and other industrial equipment.
Fireproof curtains and barriers.
Expansion joint seals in high-temperature environments.
Protective clothing and gloves for workers in heat-intensive industries.
Gaskets and seals in automotive and aerospace applications.
Thermal insulation in furnaces and kilns.
Insulation for fire doors and walls.
It is important to note that the specific properties and applications of calcium silicate coated fiberglass fabric can vary depending on the manufacturer and the precise formulation of the coating. It is recommended to consult with fabric suppliers or manufacturers for detailed information on product specifications and suitability for specific applications.





Feedback from customer

feedback from client

Features

esay to cut

environmental friendly

non flammable

non Asbestos

Applications

our feature clients

We endeavor to provide our customers with the best high-temperature textiles and personalized services. That helped us to win the trust of our customers.

Suntex Composite Industrial Co., Ltd

Suntex is Chinese leading manufacture of wide range of high quality coated textiles using fiberglass as a base material for high temperature resistance and fire protection applications.

2004 year Eastablish

600 million Square Meters of Capacity Annual

20,000 square meters Production Area

6,000,000 dollars Registered Capital

No.1 in China

Over 600 customers Worldwide
